Polyester Resin

Orthophthalic & Isophthalic Resins

VIP Global Co. supplies orthophthalic and isophthalic unsaturated polyester resins for FRP/GRP manufacturers.

We match resin chemistry, processing method, service conditions, packaging and commercial requirements to each application.

Industrial resin drums stored in a warehouse for regional supply

Choosing the Right Resin for FRP/GRP Applications

The resin system is one of the most important elements in a composite laminate. It affects processing behaviour, glass wet-out, cure profile, mechanical performance, water resistance, chemical resistance, thermal performance and long-term durability. There is no single resin that is best for every application; the correct choice depends on the operating environment and manufacturing process.

Orthophthalic Polyester Resin — Delivery Specifications

PropertyReported valueUnitTest method
Color< 2GardnerASTM D1544
AppearanceClear, slightly yellow——
Acid value18–25mg KOH/g resinISO 2114
Viscosity at 25 °C360–420mPa·sISO 2555
Density at 20 °C1.10–1.13g/cm³ASTM D1475
Solid content60–65wt.%ISO 3251
Gel time at 25 °C10–20minISO 2535
Peak time at 25 °C20–40minISO 2535
B/A (cure/gel time)< 1.8—ISO 2535
Peak temperature at 25 °C180 ± 20°CISO 2535

Values apply to the documented formulation and test conditions. Confirm the current specification for each order.

Orthophthalic Polyester Resin — Cured Resin Properties

PropertyReported valueUnitTest method
Tensile strength65 ± 5MPaISO 527-2
Tensile modulus3 ± 0.5GPaISO 527-2
Elongation at break> 3.0%ISO 527-2
Flexural strength110 ± 10MPaISO 178
Flexural modulus3.5 ± 0.5GPaISO 178
HDT75 ± 5°CISO 75-2
Barcol hardness40–45—ASTM D2583
Linear shrinkage< 3%ASTM D2566
Water absorption< 0.4%ISO 62

Values apply to the documented formulation and test conditions. Confirm the current specification for each order.

Isophthalic Polyester Resin — Delivery Specifications

PropertyReported valueUnitTest method
Color< 2GardnerASTM D1544
AppearanceClear, slightly yellow——
Acid value15–22mg KOH/g resinISO 2114
Viscosity at 25 °C300–400mPa·sISO 2555
Density at 20 °C1.10–1.12g/cm³ASTM D1475
Solid content60–65wt.%ISO 3251
Gel time at 25 °C10–20minISO 2535
Peak time at 25 °C20–40minISO 2535
B/A (cure/gel time)< 1.8—ISO 2535
Peak temperature at 25 °C180 ± 20°CISO 2535

Values apply to the documented formulation and test conditions. Confirm the current specification for each order.

Isophthalic Polyester Resin — Cured Resin Properties

PropertyReported valueUnitTest method
Tensile strength75 ± 5MPaISO 527-2
Tensile modulus3 ± 0.2GPaISO 527-2
Elongation at break> 4.0%ISO 527-2
Flexural strength115 ± 5MPaISO 178
Flexural modulus3 ± 0.2GPaISO 178
HDT85 ± 5°CISO 75-2
Barcol hardness40–45—ASTM D2583
Linear shrinkage< 1.5%ASTM D2566
Water absorption0.1–0.3%ISO 62

Values apply to the documented formulation and test conditions. Confirm the current specification for each order.

Processing, Storage and Packaging

Both resin types are styrene-dissolved unsaturated polyester systems with low viscosity and high reactivity. Listed applications include polymer concrete pipe, GRP pipes, fittings, tanks and marine components. Processing options include hand lay-up, spray-up, casting, vacuum infusion, filament winding and centrifugal winding.

Gel time and viscosity can be tailored to the agreed processing requirements. For optimum chemical, water and heat resistance, the supplied documentation recommends post-curing moulded parts: 24 hours at room temperature, followed by 3 hours at 80 °C and a further 24 hours at room temperature. The HDT test specimens use a separate post-cure of 5 hours at 105 °C.

Store indoors in unopened original packaging, dry and protected from sunlight and heat, at 5–25 °C; ideally below 20 °C, with 30 °C stated as the maximum. Higher temperatures shorten shelf life. Do not freeze. The stated shelf life is a minimum of four months from production under the specified storage conditions.

Packaging options include drums, polyethylene tanks, IBCs and containers, subject to availability and order confirmation. Follow the current SDS and supplier processing instructions.

Unsaturated Polyester Resin (UPR)

Unsaturated polyester resin is the workhorse matrix of the composite industry. It offers excellent processing flexibility and a strong cost-to-performance balance for hand lay-up, spray-up, RTM, infusion, filament winding, pultrusion, casting and SMC/BMC.

  • Orthophthalic: economical general-purpose grades for standard composite applications.
  • Isophthalic: improved water, hydrolytic and chemical resistance for tanks, pipes, marine and industrial components.
  • DCPD: often selected for low shrinkage, good surface quality and efficient moulding processes.
  • Specialty UPR: fire-retardant, low-styrene, low-emission, high-temperature and process-specific systems.

Typical Applications

GRP/FRP Pipes & Tanks

Orthophthalic and isophthalic polyester resin systems are offered for GRP/FRP pipes, fittings and tanks. Select the formulation according to the service medium, operating temperature and project requirements.

Pultrusion & Composite Rebar

Polyester resin viscosity, reactivity, reinforcement wet-out, line speed and mechanical properties should be matched to the pultrusion process and required product specification.

Marine & Water Contact

For marine and water-contact applications, validate polyester resin water uptake, laminate durability and structural performance against the intended service conditions.

RTM & Infusion

Low viscosity, controlled exotherm, gel time and reinforcement wet-out are key selection parameters for closed-mould processes.

Information Required for Resin Selection

For a technically accurate quotation, buyers should specify as much of the following information as possible:

  • Required polyester chemistry: orthophthalic or isophthalic.
  • Manufacturing process: hand lay-up, spray-up, RTM, infusion, filament winding, pultrusion, SMC/BMC or casting.
  • Promoted or unpromoted system and thixotropic or non-thixotropic requirement.
  • Target viscosity, gel time, HDT and other mechanical or thermal requirements.
  • Chemical medium, concentration, operating temperature and expected service conditions.
  • Required standards, approvals or customer specifications.
  • Packaging preference: drums, IBCs or bulk supply.
  • Required quantity and delivery destination.

Regional Supply by VIP Global Co.

VIP Global Co. supplies orthophthalic and isophthalic polyester resins throughout the region. Send your application, process, required properties, quantity, packaging preference and destination for review and quotation.
